Wear resistant ball valve

The anti erosion dual core drain valve includes a valve body, a valve seat, a valve disc, and a valve stem. The valve body has a valve chamber and inlet and outlet ports, and the valve seat is located in the valve chamber. Its feature is that the valve chamber is equipped with a valve cage, containing at least one disc, with a through hole in the middle of the disc, and at least two rings of partition walls surrounding the through hole on one side,

There are passages between adjacent partition walls, and the number of entrances to each partition wall is equal and staggered. The outermost partition wall inlet is connected to the valve body inlet, and the through-hole is connected to the valve seat, and it is a sliding channel for the valve disc.

steam trap

The anti erosion dual core drain valve includes a valve body, a valve seat, a valve disc, and a valve stem. The valve body includes a valve chamber and connected inlet and outlet ports, and the valve seat is located in the valve chamber. Its feature is that the valve chamber is equipped with a valve cage, which contains at least one disc. There is a through hole in the middle of the disc, and at least two rings of partition walls are set around the through hole on one side,

There is a passage between adjacent partition walls. The number of entrances distributed equally between each partition wall is equal, and the entrances of adjacent partitions are staggered. The outer partition wall inlet of the disc is connected to the valve body inlet, and the through-hole is connected to the valve seat, which is the channel for the valve disc to slide towards the valve seat.

Pressure piston type three arc sealing butterfly valve

The Pressure piston type three arc sealing butterfly valve stands out in the valve industry with its unique design, excellent performance and wide applicability. It not only has the advantages of simple structure, convenient operation, light weight and small volume of butterfly valve, but also further improves the sealing performance through Pressure piston technology and three arc seal design

Adjust accuracy and service life. The number of disc partition wall inlets is equal and staggered, with the outermost inlet connected to the valve body inlet, and the through-hole connected to the valve seat and serving as the valve disc channel.

26 '' -2500LB high-pressure power station gate valve

Experience Shanghai Power Station Valve Factory's 26 '' -2500LB High Pressure Power Station Gate Valve! This gate valve is designed specifically for harsh working conditions in power plants. With a diameter of 26 inches and a pressure capacity of up to 2500LB, the valve combines exquisite craftsmanship and advanced technology to ensure stable operation in extreme environments such as high pressure and high temperature.

Its outstanding performance stems from the ultimate pursuit of quality, with every detail carefully polished and rigorously tested.

DN36 PN2500 gate valve

The DN36 gate valve of Shanghai Power Station is made of high-quality materials and precision technology, with excellent sealing performance and high pressure resistance, suitable for harsh working conditions such as power stations and petrochemicals. Compact structure, flexible operation, quick opening and closing, effectively ensuring the safe and stable operation of the pipeline system.

The product undergoes strict quality inspection to ensure long-term durability, making it a reliable choice in the field of industrial fluid control.

HDs7B43R -10NiCr DN2800 seawater resistant hydraulic control check butterfly valve

Seawater resistant hydraulic control check butterfly valve

Electric gate valve Z940Y-63 DN550

DN550Z940Y-63 electric gate valve of Shanghai Power Station, with large diameter and high Pressure bearing capacity, is applicable to many industrial fields such as power, petrochemical, metallurgy, etc. It can realize remote automatic control, ensure safe and stable operation of the system, and is an important equipment for industrial pipeline valve control.

Check valve H44H-64C DN550

H44H-64C DN550 is a high-pressure cast steel swing check valve suitable for high temperature and high pressure conditions. It is mainly used in pipeline systems in industries such as petroleum, chemical, and power to prevent medium backflow.
